Pillar Candle Making Machine
Cylinder and pillar candles up to 100 mm diameter, wick-extruded or pin-formed.
Overview
A customised manual pillar candle making machine. Candle size, shape and mould quantity are designed according to your requirements and candle specifications.
The machine can be customised to produce pillar candles extruded with wick, or with pin — in the pin configuration the wick hole is formed during moulding and the wick is inserted afterwards.
Key features
- Hand-operated semi-automatic candle pouring machine — no electricity needed
- Simple operation: thread the wick, pour melted wax, cool by circulated cold water, operate the handwheel, extrude, cut the wicks and collect
- Seamless stainless steel pipe moulds for a smooth candle surface
- Candle length can be adjusted
- Service life of 15 years and more
- Designed for pillar candles and cylinder candles
Specifications
| Description | Manual pillar candle making machine |
|---|---|
| Type of candles | Cylinder candles |
| Candle diameter | 30–100 mm, customised |
| Candle length | 100–250 mm, customised |
| Candles per operation | 96 pcs, 128 pcs, customised |
| Operations per hour | 1 time per hour |
| Dimensions (L×W×H) | 148 × 60 × 120 cm |
| Gross / net weight | 290 kg / 265 kg |
| Shipping volume | 1.06 m³ |
Every figure below is a typical configuration. Candle size, mould count and machine dimensions are built to your specification.
